HE type high efficiency ultrafine Jet mill is a new type of airflow crushing equipment independently developed by our company. It is especially suitable for high hardness and high purity materials such as silicon oxide, silicon monoxide, hard carbon, etc. Combined with Zhengyuan's unique self-flow classification technology, it makes its performance far superior to other airflow mills at home and abroad.

Technical index

Raw material: silicon oxide

Feed size: <5mm

Output size: D50: 4~6μm

Features and advantages:

1. High efficiency, high output and less energy consumption, the output is 3-5 times higher than that of traditional airflow mill and the energy consumption is only 20-30% of that of traditional airflow mill.

2. High classification efficiency, the same processing volume, fine powder extraction rate is 50% higher than other classifiers.

3. The classifier adopts the original sealing method, so that there are no oversized particles and the particle size distribution is narrow.

4. Ceramic lining treatment in the material contact part, low impurity admixture.
